BRAGI HE
‘Bragi HE’ can transform any space with its presence. A spotlight and wallwasher crafted with an exceptional sense of precision — designed to deliver perfectly soft, seamless light across walls, signage, and displays without a trace of hotspots or distracting circular patterns.
BRAGI HE
65×45°
With a 65×45° beam footprint and an output of up to 4350 lumens, it provides smooth, homogenous light across walls, signage, and product displays – completely free from distracting circular patterns or unsightly hotspots. Bragi is ideal for galleries, restaurants, libraries, wine shops, museums, retail spaces, and offices – anywhere vertical surfaces or high-mounted displays require clean, even illumination.
Luminous flux
150 – 4350 lm
Connected load
11 – 31 W
Beam angle
65×45 °
UGR
N/A
Kelvin
3000K PW / 4000K PW
CRI
>90
Control
Dali, Phase Cut, Mesh Connected Ready, On/Off
Installation
Tego Systemtak (Hook) / power track
Accessories
N/A
Connector
UA
Material
Aluminium
Color
White / Black / Gray
IP class
IP20
Safety class
2
Max # / fuse
Depending on spec.
Lifespan
100 000h L90
EPREL Energy class
Contains a class E light source.
Maintenance/cleaning
Clean with lukewarm water. Dry with slightly damp all-purpose cleaning cloth. When cleaning luminaire frames, the voltage must always be disconnected. Electrical components or wiring harnesses must not be exposed to detergents or water.
The light source and/or connecting cable in this luminaire should only be replaced by the manufacturer, manufacturer’s service agent, or an equivalent qualified person. Do not connect luminaire with visible damage to cable, luminaire housing, or optic lens/LED optics.
